CommScope 4.3-10 F 7/8 EZFIT (78EZHF)

Introducing the CommScope 4.3-10 F 7/8 EZFIT Connector - 78EZHF

Upgrade your wireless and radiating connections with the CommScope Technologies LLC 4.3-10 F 7/8 EZFIT Connector (78EZHF). Designed for professionals seeking reliable and efficient connectivity, this high-quality connector from the trusted HELIAX® brand is compatible with AVA5-50 and AVA5-50FX cables.

Key Features and Benefits

• Easy installation with clamp outer contact attachment method
• High-performance 4.3-10 female interface
• Wide operating frequency band (0 – 5000 MHz)
• Low insertion loss coefficient (0.05)
• Excellent return loss/VSWR values
• Robust mechanical and environmental specifications
• Compliant with ISO 9001:2015 quality management system

Technical Specifications

The 78EZHF connector boasts a straight body style and is designed for use with AVA5-50 and AVA5-50FX cable families. It features a captivated inner contact attachment method with silver plating, and a trimetal outer contact plating. The connector has a 50 ohm impedance and operates within a frequency band of 0 – 5000 MHz.

Dimensions and Durability

Measuring 60.2 mm in length and 48.01 mm in diameter, this 7/8-inch connector is built to withstand harsh conditions. It has an operating temperature range of -45 °C to +85 °C and a storage temperature range of -55 °C to +85 °C. The connector has passed various environmental tests, including corrosion, moisture resistance, thermal shock, and vibration, ensuring its durability and longevity.

Regulatory Compliance and Certifications

The 78EZHF connector is designed, manufactured, and distributed under the ISO 9001:2015 quality management system, ensuring its compliance with industry standards and regulations.

Upgrade your connectivity today with the CommScope 4.3-10 F 7/8 EZFIT Connector (78EZHF) and experience the difference in performance and reliability. Don't settle for less when it comes to your wireless and radiating connections – choose the trusted HELIAX® brand and invest in a connector that will stand the test of time. Order now and enhance your connectivity!
