Blue Sea 30A Thermal Push-Button Quick Connect Circuit Breaker (7059)

The Blue Sea 30 Amp thermal push-button circuit breaker with quick connect terminals is used as a branch circuit breaker. This marine circuit breaker can be used for 24-hour circuit protection in your Blue Sea Systems" waterproof circuit breaker panels or main battery distribution panels. It also features push-to-reset operation, and its "trip free" design cannot be held "ON" during faulty current conditions. These marine push-button circuit breakers feature male quick connect terminals.
This marine circuit breaker is ignition protected, which makes it safe for installation aboard gasoline powered boats. Quick connect terminal style circuit breakers are used in Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels. Blue Sea Systems produces innovative electrical products engineered to operate in harsh marine environments. Solid Signal is your source for this 30 Amp thermal push button circuit breaker from Blue Sea.
Key Features

• 30 Amp push button used as a branch circuit breaker or 24-hour circuit protection in Blue Sea Systems" waterproof circuit breaker panels and main battery distribution panels
• Replaces dress nut mounting on circuit breakers and resists discoloration and cracking
• Compact design enables high-density circuit protection configurations
• Push-to-reset operation
• Optional push button waterproof boot protects circuit breaker in wet environments
• Amperage: 30A
• Maximum Voltage: 32V DC
• Mounting: Panel Mount 3/8-27 UNS
• Circuit Breaker Type: Thermal trip, manual push-button reset only
• Terminal Type: 1/4 Male Quick Connect
• Interrupt Capacity: 3000A @ 14.7V; 2500A @ 28V
• Minimum Operating Temperature: -10° C
• Maximum Operating Temperature: 60° C
