CommScope N-Male 1/2in LDF4-50A (L4PNM-H)

Introducing the CommScope N-Male 1/2in LDF4-50A (L4PNM-H) Connector

Upgrade your wireless and radiating connections with the high-quality CommScope N-Male 1/2in LDF4-50A (L4PNM-H) connector. Designed for professionals who demand the best performance, this connector is part of the renowned HELIAX® product series and is compatible with LDF4-50A cable family.

Key Features and Benefits

• Gold-plated inner contact for optimal signal transmission
• Trimetal outer contact plating for enhanced durability
• Self-flare outer contact attachment method for easy installation
• Wide operating frequency band (0 – 8800 MHz) for versatile use
• Low insertion loss coefficient (0.05) for minimal signal loss
• High connector retention tensile force (200 lbf) for secure connections
• Environmentally friendly, RoHS compliant design

Technical Specifications

With a straight body style and solder inner contact attachment method, the CommScope N-Male 1/2in LDF4-50A (L4PNM-H) connector offers a reliable and secure connection. The connector is not pressurizable and has dimensions of 66.04 mm (2.600 in) in length and 25.4 mm (1.000 in) in diameter.

Electrical specifications include a 50-ohm cable and connector impedance, maximum inner contact resistance of 2 mOhm, and a maximum RF operating voltage of 707 V (vrms). The connector also boasts impressive return loss/VSWR values across various frequency bands.

Mechanical specifications include a connector retention torque of 5.42 N-m (47.998 in lb) and a coupling nut proof torque of 4.52 N-m (39.997 in lb). The connector is designed to withstand 25 attachment cycles and has an interface durability of 500 cycles.

Environmental specifications include an attenuation ambient temperature of 20 °C (68 °F) and an average power ambient temperature of 40 °C (104 °F). The net weight of the connector is 108.86 g (0.24 lb).

Regulatory compliance and certifications include ISO 9001:2015, RoHS.

Upgrade Your Connections Today

Don't settle for subpar connections. Invest in the CommScope N-Male 1/2in LDF4-50A (L4PNM-H) connector and experience the difference in performance and reliability. Order now and elevate your wireless and radiating connections to new heights.
