Microlab FXR 137-960 MHz 6 dB Low PIM Tapper N-Connector (DN-51FN)

This series of Tappers unevenly split high power cellular signals with minimal reflections or loss over the key wireless bands, the innovative asymmetric design ensures an excellent input VSWR and coupling flatness across specified bands. The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced.
Key Features

• Frequency Range 137-960 MHz
• Nominal Coupling 6 dB
• PIM Typical -161 dBc
• Outputs: 2
• Maximum Power 500 W
• RF Connectors N-Female
• Dimensions 2" L x 5.8" W x 1.6" H
