Microlab FXR 3-Way Divider 694-2700 MHz 4.3-10 Female (D3-85FE)

Microlab Model Dx-85FE series of 2, 3, 4 and 6 way Power Splitters have been designed to evenly split high power cellular signals with minimal reflections or loss. All joints are moisture sealed to meet the IP67 rating.

Special Order. Non-Cancellable and Non-Returnable

Key Features

• Frequency Range 694-2700 MHz
• Loss 4.8 dB
• PIM Typical -161 dBc
• Maximum Power 500 W
• Maximum VSWR 1.15:1
• RF Connectors 4.3-10 Female
