Microlab/FXR 380-960 / 1710-2700 MHz Multband Unequal Power (DN-14FN)

Microlab DN-14FN series of Tappers unevenly split high power cellular signals in fixed ratios from 1000:1 to 2:1 with minimal reflections or loss over the key wireless bands in the range 380 - 5,850 MHz, (there is no coupling 1550 to 1650 MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands.

Special Order. Non-Cancellable and Non-Returnable

Key Features

• Frequency Range 380-960 / 1710-2700 MHz
• Maximum Power 500 W
• Nominal Coupling 30 dB
• Maximum VSWR 1.2:1
• PIM Typical -161 dBc
• RF Connectors N-Female
• Dimensions 5.52" L x 2" W x 1.6" H
• Mfg. Warranty 1 year
