Microlab FXR 694-2700 MHz 8-Way Splitter (D8-69FN)

The D8-69FN Hybrid Coupler has been designed to meet the special needs of the higher power needs of the wireless market. The most common use is to combine two wireless carriers in the band to a single antenna feed or distribution cable. This requires the termination of one output port in 50O and results in a 3 dB loss in each signal. Note that the termination used must have a return loss of at least 25 dB and PIM below -153 dBc for the isolation and PIM performance to be maintained. A high power low PIM cable load appropriate to the power dissipation is recommended to maintain this performance. Outdoor rated.
Key Features

• Frequency Range 694-2700 MHz
• Minimum Isolation 20 dB
• Loss 10 dB
• Maximum VSWR 1.4:1
• Product Eight Port Power Dividers
• Dimensions 6.3" L x 1.0" W x 1.0" H

Special Order. Non-Cancellable and Non-Returnable
