Microlab FXR Tapered Stripline 694-3600 MHz 20 dB (CK-18E)

The Microlab/FXR CK-18E Directional Coupler is a tapered stripline design covering from 694 to 3,600 MHz. Units couple off a defined fraction of the signal with minimal reflections or loss. The extremely wide frequency range allows use with multiband antennas, leaky cable systems, and wireless base stations. With minimal solder joints and a low loss dielectric, the dissipative loss has been minimized and reliability enhanced.
Key Features

• Frequency Range 694-3600 MHz
• Nominal Coupling 20 dB
• Coupled Loss 0.04 dB
• Ultra wide-band, taper design
• Maximum Power 200 W
• Maximum Input Power: 0.5 W (27 dBm)
