Microlab FXR Tappers 350-5850 MHz 15 dB (DN-94FE)

Microlab DN-94FE is a series of Tapper's unevenly split high power cellular signals with minimal reflections or loss over the key wireless bands, the innovative asymmetric design ensures an excellent input VSWR and coupling flatness across specified bands. The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced.
Key Features

• Frequency Range 350-5850 MHz
• Nominal Coupling 15 dB
• PIM Typical -161 dBc
• Maximum Power 500 W
• RF Connectors 4.3-10 Female
• Maximum VSWR 1.3:1
• Dimensions 4.02"L x 1.25"W x 2.06"H
