NewMar 12VDC 35A DIN Rail UPS (DIN-UPS-12-35)

NewMar 12VDC 35A DIN Rail UPS: Power, Protection, and Performance

Key Features and Benefits

Introducing the NewMar 12VDC 35A DIN Rail UPS, a compact power system that combines all your power needs into one efficient unit. This innovative product offers a power supply, battery charger, and status monitoring, all in a compact DIN rail mount unit.

• Mounting Type: DIN Rail
• Power Source Type: DC
• AC Input Voltage Range: 90-264V
• Crowbar Protection: YES

Technical Specifications

The NewMar DIN Rail UPS operates on a 115/230 input VAC, 12 VDC, and 10 amp output. It features separate outputs for load and battery, ensuring power is dedicated first to the load, with the remainder allocated to battery charging. This prevents a discharged battery from impacting the operation of critical loads.

With its 3 step charging system, it offers rapid battery recovery, programmable for battery type, with an optional temperature compensation sensor. The battery automatically supports the load anytime AC fails, and a low voltage disconnect protects the battery from total discharge.

Compact and Efficient Design

Measuring just 5.9" x 2.6" x 5.3", the NewMar DIN Rail UPS is designed to fit seamlessly into your existing setup. Despite its compact size, it delivers powerful performance and reliable protection for your power needs.

Reliable Power Supply

With the NewMar DIN Rail UPS, you can trust that your power supply is secure. The load priority circuit ensures that power is dedicated first to the load, preventing a discharged battery from impacting the operation of critical loads.

Advanced Battery Protection

The NewMar DIN Rail UPS features a low voltage disconnect that protects the battery from total discharge. This ensures the longevity of your battery and the reliability of your power supply.

Experience the power, protection, and performance of the NewMar DIN Rail UPS. Upgrade your power system today and enjoy peace of mind knowing your power supply is secure.
