BZBGEAR 4x1 1080P FHD HDMI MultiViewer with KVM USB2.0 Ports and Support for up to 4 Computers/Laptops(BG-MKVM41R)

  • Brand: BZBGEAR
  • P\N: BG-MKVM41R
  • UPC: 850023208019
(0)No Reviews yet

Availability: In Stock


Your Price: $239.20 Listing Price: $299.00

Do you have questions?

Please contact our experts for assistance.

Description

4x1 HDMI Multiviewer with KVM and USB 2.0 (BG-MKVM41R)


Best For

Multi-computer workstations, conference rooms, industrial control areas, and surveillance applications needing to view and control up to four computers from one display, keyboard, and mouse.

Why Choose It?

The BG-MKVM41R combines a four-input HDMI multiviewer with KVM switching and USB 2.0 peripheral sharing, including quad-view and full-screen display modes.

Key Benefits

  • Four HDMI/USB 2.0 PC host connections
  • One HDMI output
  • View up to four computers simultaneously in quad-view
  • Full-screen switching
  • HDMI output resolutions up to 1080p at 60 Hz stated in existing information
  • HDMI 1.3a and HDCP 1.2 compliance stated in existing information
  • Mouse/keyboard hot-key switching
  • Front-panel and IR remote control
  • RS-232 control
  • Two USB 2.0 device ports for sharing compatible peripherals

Who Should Buy It?

IT, AV, control-room, and surveillance users who have confirmed computer video output, USB/KVM compatibility, display resolution, HDCP requirements, peripheral support, and control method.

Specifications

Signal Inputs/Output
Maximum Single Link Range1920×1080@60
HDMI Input/Output ConnectorType A 19 pin
Operating Frequency
Vertical Frequency Range50/60Hz
Video Amplifier Bandwidth2.25Gbps
Resolutions
Input Resolution480i60Hz, 480p60Hz, 576i50Hz, 576p50Hz, 720p50/60Hz, 1080i50/60Hz, 1080p24/25/30/50/60Hz
Output Resolution720p, 1080p
Mechanical Data
Chassis MaterialMetal
ColorBlack
Environmental
Operating Temperature32°F to +158°F / 0°C to +70°C
Operating Humidity10% to 85% RH (no condensation)
Storage Temperature14°F to 176°F / -10°C to +80°C
Storage Humidity5% to 90% RH (no condensation)
Power Requirement
External Power Supply12V DC@2A
Power Consumption (max)24W
Regulatory Approvals
Main UnitFCC, CE
Power SupplyUL, CE, FC C, REACH, ROHS

Downloads
