AVANT 12 programmable multiband amplifier for terrestrial, 32 digital filters and programming via ASuite (Bluetooth®)

Televes AVANT 12 Programmable Multiband Amplifier

Best For

Professional terrestrial-TV and MDU distribution systems that need programmable filtering, amplification, and balancing of channels from multiple antenna inputs.

Why Choose the Televes AVANT 12?

The AVANT 12 provides 32 digital filters across configurable terrestrial inputs and supports wireless programming through the Televes ASuite application using its built-in Bluetooth interface.

Key Benefits

• 32 programmable digital channel filters
• Five inputs configurable as FM plus four VHF/UHF inputs or FM, DAB, and three UHF inputs
• Programmable amplification and balancing of RF inputs
• Automatic channel-level adjustment
• Manual fine adjustment by channel
• ASuite programming from compatible Android/iOS devices
• Bluetooth connectivity built in
• Configurable antenna powering
• Import/export of configurations
• 4G/5G filtering through the supported terrestrial channel range

Who Should Buy the AVANT 12?

Professional TV-system installers designing individual or multi-dwelling terrestrial distribution systems that require channel-level control rather than simple broadband amplification.

• With the ASuite application, advanced programming of the device can be carried out wirelessly (Bluetooth®), easily and conveniently from a smartphone or tablet (Android/iOS)
• Single device with 2 distribution modes: 4 inputs support VHF/UHF, or one input is for DAB and the other 3 for UHF
• High output level: up to 128dBµV (EN50083), to reach a large number of outlets
• Up to 32 individually programmable filters, with individual digital filtering of each channel, including adjacent channels
• Digital processing of the channels, resulting in a perfectly balanced signal level between the different channels at the output
• Automatic signal regulation in each filter (AGC). Also allows fine adjust of the output level after regulation
• High selectivity VHF/UHF digital filters: >30dB rejection (@ 1MHz)
• SAW (Surface Acoustic Wave) filter for rejection of 4G/5G signals from channel 48, with the best selectivity and stability
• DVB-T and DVB-T2 compatible
• TForce technology: terrestrial signal level is always balanced and adjusted to the optimum value
• Power supply at the inputs for antenna powering, when the signal requires it
• LED status indicator as well as physical autoadjust button built into the control panel
• High shielding chassis (Zamak) to protect against electromagnetic interference
• Very light and compact size for a high performance control unit (196x122x43mm)
• 100% European design and manufacture: fully automated manufacturing and subjected to rigorous quality controls
