Televes SmartKom intelligent amplifier with automatic and advanced programming, with ASuite app (531983)

Televes SmartKom Intelligent 3-Input TV Amplifier with ASuite App (531983)

Best For

Homes and professional over-the-air TV installations that need to combine multiple VHF/UHF antennas from different directions while filtering and balancing individual TV channels.

Why Choose the Televes SmartKom?

SmartKom combines filtering, combining, and amplification in one outdoor preamplifier. Its three inputs and 32 programmable digital filters allow installers to select, combine, and level channels from different antenna sources, while the included ASuite app supports both automatic and advanced Bluetooth programming.

Key Benefits

• Three VHF/UHF antenna inputs
• 32 programmable digital channel filters
• Automatic channel scan, filtering, and level balancing
• Advanced per-channel programming through the ASuite app
• Bluetooth programming through the included power supply interface
• Automatic gain control on each filter
• LTE/5G out-of-band filtering
• Compatible with HDTV, UHD 4K, and supported ATSC 3.0 signals
• Configuration retained after power loss
• 12V, 750mA power supply included

Who Should Buy the 531983?

OTA installers combining antennas aimed at different broadcast sites who need more control than a passive splitter or combiner can provide.

Installation Notes

SmartKom is intended for outdoor installation and is powered remotely through the coaxial output. Automatic mode is designed for fast setup; advanced mode is intended for installers who need manual channel selection and level adjustment.

• "All-in-one" device: it combines the functions of several functions needed in an installation including filters, combiners and amplifiers, supplying a complete signal distribution under a single coaxial cable
• With the ASuite application it is possible to program the device wirelessly (Bluetooth®), either automatic or advanced, avoiding the need to physically climb the mast
• Autoprogramming: with this function available in ASuite, the preamplifier performs channel filtering and level adjustment by itself, as well as powering the antennas when it detects that the signal requires it
• Advanced programming: professionals can perform a more customized configuration in ASuite, selecting the desired channels on each of the inputs and adjusting the levels of each channel
• Automatic gain regulation of signal in each filter (AGC) and wide dynamic range in each filter adjusts all carriers to the same power

• Great signal quality: its digital processing minimizes severe signal loss, co-channel interference, as well as multipath and phasing interference common with conventional splitters/combiners

• Compatible with existing HDTV signals and UHD 4K stations (NextGen TV / ATSC 3.0)

• Undesired out of band and cell phone LTE/5G signals are filtered to avoid interference

• Secure configuration: in case of loss of power, SmartKom saves the current configuration, avoiding the need to configure it again
• Remote powering, through the coaxial cable

• LEDs status indicators, as well as both adjustment and programming physical buttons on the preamplifier and on the power supply
• High shielding chassis (Zamak) to protect against electromagnetic interference

• Weather resistant: the device is housed inside a sturdy weather resistant case

• Static installation: SmartKom does not require moving mechanical parts that are prone to failure

• 100% European design and manufacturing: fully automated manufacturing, subject to the most stringent quality controls

*¹ With adjacent channels: >30dB (@1MHz) // Without adjacent channels: >50 dB (@6MHz)

*² With adjacent channels: >30dB (@1MHz) // Without adjacent channels: >50 dB (@6MHz)

*³ With adjacent channels: >30dB (@1MHz) // Without adjacent channels: >50 dB (@6MHz)
