Blonder Tongue Broadband Distribution Amplifier 49-750MHz 43dB (BIDA-75A-43)
- Brand: Blonder Tongue
- P\N: BIDA-75A-43
Do you have questions?
Please contact our experts for assistance.
Description
Description
Blonder Tongue Broadband Distribution Amplifier 49-750MHz 43dB (BIDA-75A-43)
Experience the professional quality of the Blonder Tongue Broadband Distribution Amplifier. This two-way broadband indoor distribution amplifier is perfect for multi-channel RF distribution systems where the input source is a "cable drop" or the output of a MATV/SMATV/CATV headend.
Key Features
- Provides two-way capability with passive or active return path set by field-changeable jumpers
- Easily adjustable front panel gain and slope controls
- Hybrid IC circuitry for high output and low distortion
- Integrated return path configurable for either passive or active operation
- Input and output test ports
- Large heat sinks for exceptional heat dissipation
The Blonder Tongue Broadband Distribution Amplifier boasts a frequency range of 49-750MHz and 43dB gain. It employs push-pull and power doubling hybrid amplifier technologies. The amplifier leaves the factory ready for passive return path operation. However, an active return path operation can be achieved by reconfiguring a few internal jumpers.
This amplifier utilizes an external power transformer providing 26 VAC to the amplifier. This feature enables the amplifier to be remotely powered via low voltage AC wiring should a 120 VAC electrical outlet not be in close proximity to the desired amplifier location.
Easy to Use
With its easily adjustable front panel gain and slope controls, the Broadband Distribution Amplifier is user-friendly. It also features input and output test ports for easy monitoring of your system.
Exceptional Heat Dissipation
Large heat sinks ensure that the amplifier remains cool, even under heavy load. This feature extends the life of the amplifier and ensures reliable performance.
Experience the difference that professional quality can make in your multi-channel RF distribution system. The Blonder Tongue Broadband Distribution Amplifier delivers high output and low distortion, making it the ideal choice for your system.
Don't wait. Enhance your multi-channel RF distribution system with the Blonder Tongue Broadband Distribution Amplifier today!
