Harger 3.75 x 2.5 Inch Flange Bonding Plate (223T)

Harger 3.75 x 2.5 Inch Flange Bonding Plate (223T)

Key Features and Benefits

Experience the superior performance of the Harger Flange Bonding Plate. This robust and versatile bonding plate is designed to provide an extensive bonding surface, ensuring a secure and reliable connection for your electrical systems.

• Covers 8 square inches of contact area for a robust and secure connection
• Accommodates all main size conductors up to 500 MCM or 9/16" in diameter
• Large cable connector offers 3" of contact between the bonding plate and the cable
• Ideal for both direct burial in the earth and concrete, offering versatility in installation
• Recommended to use a 1/2" socket wrench, end wrench, or nut driver for installation, ensuring a tight and secure fit

Technical Specifications

The Harger Flange Bonding Plate measures 3.75" x 2.5" and weighs 2.03 lbs. It uses 2 5/16 bolts to clamp onto steel I-beam flanges up to 1" thick. This plate is designed to accommodate all main size conductors up to 500 MCM or 9/16" diameter.

Installation Instructions

Before applying the plate, it is crucial to properly prepare the bonding surface. Remove all paint, rust, moisture, and debris. The use of a rasp or grinding tool is recommended to ensure all surface oxidants have been removed. Generously coat the bonding surface with the appropriate antioxidant, then install the bonding lug or plate.

Experience the difference that a high-quality bonding plate can make in your electrical systems. The Harger Flange Bonding Plate is designed to provide a secure and reliable connection, ensuring the optimal performance of your systems. Don't settle for less, choose Harger for your bonding plate needs.

Upgrade your electrical systems with the Harger Flange Bonding Plate today. Experience the difference that quality makes.
