PCTEL 450-470 MHz 10.2dB 6 Element Yagi Antenna (MYA4506N)
- Brand: PCTEL
- P\N: MYA4506N
- UPC: 729198376345
Do you have questions?
Please contact our experts for assistance.
Live Chat
Contact Us
Call Our Experts
Description
PCTEL 450-470 MHz 10.2dB 6 Element Yagi Antenna (MYA4506N)
PCTEL's MYA4506N Maxrad 450 – 470 MHz directional yagi antenna 6 element, 10.2 dB gain, 300 W, N Female termination includes mounting hardware.
Specifications
| Item Weight | 2.5 lbs. |
| Gain dBi (dBi) | 12.3 dBi |
| Gain dBd | 10.2 dBd |
| Item Length | 42 inch |
| Horizontal Beamwidth | 42 deg |
| Jumper Included | No |
| Maximum Power (W) | 300 |
| Polarization | Linear |
| RF Connectors | N Female |
| Vertical Beamwidth (Deg) | 40 |
| Specific Frequency | 450-470 MHz |
| Maximum Rated Wind Velocity | 100 miles/hour |
| Maximum VSWR | 1.5:1 |
| Minimum Front Back Ratio | 20 dB |
| Lightning Protection | DC Ground |
| Frequency Band | UHF |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.govReviews
1 review
Using for over 20 years
by Art Wilson
I have been using these models of uhf yagis for over 20 years with great success. They are inexpensive and last a long time. No assembly and now n connectors come standard on the antenna.
