Blue Sea 100A Toggle Switch for Inverters/Bow Thrusters/Windlasses (7250I)

This Blue Sea 100 Amp toggle switch provides overcurrent protection for inverters, bow thrusters, and windlasses. This toggle switch is "trip free," which means it cant be held closed after a trip. It is ignition protected for installation aboard gasoline-powered boats. This Blue Sea toggle features a red switch, and mounts using a #6-32 stainless steel screw.
This marine switch is part of Blue Seas C-series. These toggle switches, flat rockers, and raised rockers are magnetic hydraulic circuit breakers that combine switching and circuit protection into a single device. This is a single pole toggle switch, which means it is used to control one circuit. Solid Signal provides the solution you need with this 100 Amp single pole toggle switch from Blue Sea Systems.
Key Features

• Provides overcurrent protection for inverters, bow thrusters, and windlasses
• Amperage: 100A AC/100A DC
• Maximum voltage: 240V AC/48V DC
• Minimum/maximum operating temp: -40 degrees C/85 degrees C
• Interrupt capacity: 1,500A @ 125V AC/5,000A @ 48V DC
