CommScope 1-Foot Gray Elliptical Waveguide 14.4-15.35 GHz (35409-14)

Introducing the CommScope 1-Foot Gray Elliptical Waveguide 14.4-15.35 GHz (35409-14)

Upgrade your communication system with the high-performance CommScope 1-Foot Gray Elliptical Waveguide 14.4-15.35 GHz (35409-14). Designed for professionals who demand the best, this waveguide offers exceptional signal transmission and reliability. With its advanced features and durable construction, you can trust this waveguide to deliver the performance you need.

Key Features and Benefits

• High-quality HELIAX® elliptical waveguide for superior signal transmission
• Wide operating frequency band of 14.4 – 15.35 GHz for versatile use
• Low attenuation and high return loss for optimal performance
• Corrugated copper conductor for enhanced durability
• Non-halogenated, fire retardant polyolefin jacket for added safety
• Compliant with ISO 9001:2015 and UL/ETL Certification

Technical Specifications

With its impressive technical specifications, the CommScope 1-Foot Gray Elliptical Waveguide 14.4-15.35 GHz (35409-14) ensures reliable performance in various applications. The waveguide features a diameter over the jacket of 24.4 mm (E Plane) and 15.5 mm (H Plane), with a cable volume of 167 L/km. The operating frequency band ranges from 14.4 to 15.35 GHz, with low attenuation and high return loss for optimal signal transmission.

The waveguide's conductor material is made of corrugated copper, while the jacket material is non-halogenated, fire retardant polyolefin. This ensures durability and safety in various environments. The waveguide also has a minimum bend radius of 130 mm (E Plane) and 360 mm (H Plane) for multiple bends, and a maximum twist of 6.562 °/m.

Environmental specifications include an installation temperature range of -25 °C to +60 °C, an operating temperature range of -30 °C to +80 °C, and a storage temperature range of -30 °C to +80 °C. The waveguide has passed the UL 1666/CATVR/CMR fire retardancy test and the IEC 60754-2 toxicity index test.

With a cable weight of 0.33 kg/m, this waveguide is designed for easy installation and handling. It is also compliant with ISO 9001:2015 and UL/ETL Certification, ensuring that it meets the highest quality standards.

Upgrade your communication system today with the CommScope 1-Foot Gray Elliptical Waveguide 14.4-15.35 GHz (35409-14) and experience the difference in performance and reliability. Don't settle for less – choose the best with CommScope.
