Microlab FXR - 350-5850 MHz 10dB Low PIM Tapper (DN-74FE)

  • Brand: Microlab FXR
  • P\N: DN-74FE
  • UPC: 729198870744
(0)No Reviews yet

Availability: In Stock


Your Price: $161.00

Do you have questions?

Please contact our experts for assistance.

Description

Description

Microlab DN-x4FE series of Tappers unevenly split high power cellular signals in fixed ratios from 1000:1 to 2:1 with minimal reflections or loss over the key wireless bands in the range 350 - 5,850 MHz, (there is no coupling 1550 to 1650 MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split.

Key Features
  • Frequency Range: 350-5850 MHz
  • Nominal Coupling: 10 dB
  • PIM Typical: -150 dBc
  • Maximum Power: 500 W
  • RF Connectors: 4.3-10 Female
  • Maximum VSWR: 1.2:1
  • Mfg. Warranty: 1 Year
