Microlab/FXR Multi Band Unequal Power Tapper (DN-04FN)

Microlab DN-04FN series of Tappers unevenly split high power cellular signals in fixed ratios from 1000:1 to 2:1 with minimal reflections or loss over the key wireless bands. The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split

Special Order. Non-Cancellable and Non-Returnable

Key Features

• Frequency Range 380-960 MHz / 1710-2700 MHz
• Nominal Coupling 20 dB
• PIM Typical -161 dBc
• Maximum Power 500 W
• RF Connectors N-Female
• Maximum VSWR 1.25:1
• Dimensions 5.52" L x 2" W x 1.6" H
• Mfg. Warranty 1 year
