Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof (206-051S)

  • Brand: Paneltronics
  • P\N: 206-051S
  • UPC: 602290201404
(0)No Reviews yet

Availability: In Stock


Your Price: $26.99

Do you have questions?

Please contact our experts for assistance.

Description

Description

Panel Seal-Waterproof "A" Frame Magnetic Circuit Breakers. This branch AC or DC circuit breaker for Paneltronics electrical distribution panels. It meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers and UL Recognized (UL 1077) for use in the USA, and CSA Certified for use in Canada. Also, it is Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1), Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1). With the handle color - Metal with a silicone rubber seal, Maximum Amperage - 50 Amps, Maximum Voltage/AIC - 32 VDC/2,500 amps with no backup fuse (ABYC E-11.10.1.5.5). Rated Switch Cycles - 10,000 actuations at rated current and voltage, Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker).
