PolyPhaser GPS & Tower Top Protector NF-NM (DGXZ-36NMNF-A)

POLYPHASER 800-2500 MHz protector. Used in installations when DC is required to pass in route to powering shelter-based equip. +36 VDC. TNC/F. Type: DC Pass Frequency range: 800-2500 MHz Protected side connector: TNC(F) Surge side connector: TNC(F) Mounting type: bulkhead Gas tube (Y/N): N Multi-strike (Y/N): Y Depth: 2.8' Width: 3.6' Height: 1.3' Weight: 0.7 LB Warranty: 10 years Shipping: Parcel Freight

Key Features:

• Line Voltage:36 VDC
• Frequency Range:800-2500 MHz
• Maximum Power:300 W
• Turn On Voltage:40 VDC
• Nominal Insertion Loss:0.1 dB
• RF Power:300W
