WilsonPro Cellular Network Scanner 5G (910060)

WilsonPro Cellular Network Scanner 5G

Easily obtain an accurate, comprehensive cell signal scan with the Cellular Network Scanner 5G from WilsonPro. Designed for the future of 5G, the scanner quickly identifies nearby towers, different local carrier networks, and the strength and quality of different frequencies. The scanner detects and analyzes low band frequencies and frequencies of C-Band and CBRS signals using either LTE or 5GNR modulation. Use the scanner to optimize the design and installation of a cellular repeater solution, from the planning phase to testing the completed system.

FEATURES

• Scans all carriers regardless of the carrier phone running the app
• Provides comprehensive scanning of 4/5/12/13/14/25/41/66/71/77, and 48 frequency bands
• Supports International Bands 1(2100), 3(1800), 7(2600), 20 (800), & 28 (700)
• Scans 5G, including C-Band CBRS signals
• Identifies 5GNR signals
• Backwards compatible with 4G (LTE)
• Identifies individual carriers and towers
• Offers details on location, tower ID, distance to tower, and more
• Pinpoints active carriers and geo-maps any active cells within range
• Captures all scan results, including time stamps for A/B comparisons
• Links via Bluetooth to iOS or Android with the Cell LinQ app from WilsonPro
• Exports data as .csv files for easy use in Excel

Scan. Plan. Install.

The Cellular Network Scanner 5G pairs with the CellLinQ app from WilsonPro for easy project management and data export. The app conveniently organizes and displays your data, providing detailed analysis of any cell signals you scan.
